In order to improve the precision of large-diameter flange machinery, it is necessary to ensure that each large-diameter flange part has a certain processing and installation accuracy. In addition, the parts should have a certain rigidity to ensure that the accuracy requirements can be met under the working load. The parts should also have high wear resistance to maintain the accuracy. In addition, the design should also consider the use of large-diameter flanges for a period of time. After the accuracy is reduced, it can be improved by adjusting, repairing or replacing some parts, and it can restore the accuracy of the universe.
The first thing to pay attention to is to reasonably confirm the overall orangeness requirements of the flange according to the service requirements. In addition, it is necessary to analyze the influence of each component error on the overall accuracy, and select a reasonable mechanical design and structure from the perspective of accuracy.
In the structural design, the overall structure of the large-diameter flange and the fine structure of the parts may have a certain impact on the accuracy. When planning, it is necessary to conduct a comprehensive analysis of various factors that affect the accuracy, and put forward the accuracy requirements for the parts of the large-diameter flange according to the overall requirements, and pay special attention to some key parts that have the greatest impact on the accuracy.
It is necessary to confirm the accuracy requirements for the size and shape of parts and allow errors. In addition, the influence of various forces such as load, gravity, inertial force, processing, and installation should be considered; how to ensure accuracy, as well as heat, vibration, etc. and other factors.
